040119V-AUX ENGINE HIMSEN 7H21/32

AUX ENGINE DATA:O-RING

HHI CO. LTD.H21-32.13.249

THRUST BEARING

HHI CO. LTD.H21-32.13.252

Model: HYUNDAI - HIMSEN 7H21/32

1045 kW / 1420 bhp at 720 rpm

Engine No: BA1547-1, BA1547-2, BA1547-3

Number of cylinder: 7

Cylinder bore: 210 mm, Stroke: 320 mm, Firing order: 1-2-4-6-7-5-3

MAKER: HYUNDAI HEAVY INDUSTRIES CO.,LTD - 2005 YEAR.

NAME OF DRAWING: DIESEL GENERATOR ENGINE(VOL.I), DRAWING NO: 6U-2831-101.

SECTION: M.13.200, PAGE: A1, REVISION: 1, POSITION: 6, PART: 13.251.

SECTION: M.13.200, PAGE: A1, REVISION: 1, POSITION: 9, PART: 13.249.

SECTION: M.13.250, PAGE: A1, REVISION: 2, POSITION: 3, PART: 13.252.

MAIN BEARING (UPPER+LOWER)

HHI CO. LTD.H21-32.13.251
